Thermal-Link & Fusing Resistor (TRXF)
Applications

Thermal-Link & Fusing Resistor (TRXF)

Manufacturer
Overview
Glossary
Mounting Style
Termination Style
Applications
Quality Assurance
Attention
Brand
Tradename
Ad
Catalog

Power Type (W)
1
2

Rated Resistance (Ω)

0.27
0.3
0.33
0.36
0.39
0.43
0.47
0.51
0.56
0.62
0.68
0.75
0.82
0.91
1
1.1
1.2
1.3
1.5
1.6
1.8
2
2.2
2.4
2.7
3
3.3
3.6
3.9
4.3
4.7
5.1
5.6
6.2
6.8
7.5
8.2
9.1
10
11
12
13
15
16
18
20
22
24
27
30
33
36
39
43
47
51
56
62
68
75
82
91
100
110
120
130
150
160
180
200
220
240
270
300
330
360
390
430
470
510
560
620
680
750
820
910

Resistance Tolerance (%)

±10
±5

Agency Approvals

Product Series

TRXF1S
TRXF1
TRXF2
TRXF1(Axial Type)
TRXF2(Axial Type)

Structure Type

Rated Functioning Temp.

Applications

TRXF1S series
Power Type (P): 1 W
Rated Resistance (R): 1 ~ 600 Ω
Rated Functioning Temp. (Tf): 145 / 221 ℃
Φ3.6 × 11 mm
TRXF1 series
Power Type (P): 1 W
Rated Resistance (R): 0.27 ~ 800 Ω
Rated Functioning Temp. (Tf): 145 / 221 ℃
Φ4.8 × 11.0 mm
TRXF2 series
Power Type (P): 2 W
Rated Resistance (R): 0.27 ~ 1000 Ω
Rated Functioning Temp. (Tf): 150 / 221 ℃
Φ4.8 × 13.5 mm
TRXF1 (Axial Type) series
Power Type (P): 1 W
Rated Resistance (R): 0.27 ~ 800 Ω
Rated Functioning Temp. (Tf): 221 ℃
Φ4.4 × 9.5 mm / Φ4.6 × 9.5 mm (Tube)
TRXF2 (Axial Type) series
Power Type (P): 2 W
Rated Resistance (R): 0.27 ~ 1000 Ω
Rated Functioning Temp. (Tf): 221 ℃
Φ4.4 × 10 mm / Φ4.6 × 10.5 mm (Tube)

TRXF1S series
Power Type (P): 1 W
Rated Resistance (R): 1 ~ 600 Ω
Rated Functioning Temp. (Tf): 145 / 221 ℃
Φ3.6 × 11 mm

TRXF1 series
Power Type (P): 1 W
Rated Resistance (R): 0.27 ~ 800 Ω
Rated Functioning Temp. (Tf): 145 / 221 ℃
Φ4.8 × 11.0 mm

TRXF2 series
Power Type (P): 2 W
Rated Resistance (R): 0.27 ~ 1000 Ω
Rated Functioning Temp. (Tf): 150 / 221 ℃
Φ4.8 × 13.5 mm

TRXF1 (Axial Type) series
Power Type (P): 1 W
Rated Resistance (R): 0.27 ~ 800 Ω
Rated Functioning Temp. (Tf): 221 ℃
Φ4.4 × 9.5 mm / Φ4.6 × 9.5 mm (Tube)

TRXF2 (Axial Type) series
Power Type (P): 2 W
Rated Resistance (R): 0.27 ~ 1000 Ω
Rated Functioning Temp. (Tf): 221 ℃
Φ4.4 × 10 mm / Φ4.6 × 10.5 mm (Tube)

Xiamen SET Electronics Co., Ltd.

Thermal-Link & Fusing Resistor (TRXF) is an unique type of Power Resistor, with Over Temp. and Over Current Protections. The Alloy Thermal-Link (ATCO) is built in the core of Fusible Wirewound Resistor (RXF) and in series with RXF.

SETsafe | SETfuse TRXF has the same physical size as ordinary RXF as well as large fault current protection. Besides, TRXF can effectively solve the hidden danger of continuous abnormal heat that ordinary RXF may cause when small fault current happens.

Overview 1-2_TRXF.jpg

RXF

Fusible Wirewound Resistor

A power resistor which is made by winding a resistive element on a ceramic core, and the core is coated by insulation coating. It intends to interrupt a current flow at a predetermined time when the current exceeds a predetermined value. Fusible Wirewound Resistor is disposable fuse elements and is non-recoverable.

— (SETsafe | SETfuse Standards)

ATCO

Alloy Thermal-Link

Alloy Type Thermal-Link, Alloy is the thermal element.

— (GB/T 9816.3)

Rated Resistance

Resistance value for which the resistor has been designed, and which is generally used for denomination of the resistor.

— (IEC 60115-1)

P₀

Actual Power

The Max. power of TRXF can be used within the allowable operating Temp. range.

— (SETsafe | SETfuse Standards)

I_N

Rated Current


— (SETsafe | SETfuse Standards)

U_N

Rated Voltage

The d.c. or a.c. r.m.s. voltage calculated from the square root of the product of the rated resistance and the rated dissipation.

— (IEC 60115-1)

T_f

Rated Functioning Temp.

The temperature of the Alloy Thermal-Link which causes it to change the state of conductivity with a detection current up to 10 mA as the only load.

— (IEC 60691)

Tolerance: T_f °C (GB/T 9816, EN 60691, K60691).

Tolerance: T_f ± 7 °C (J60691).

Fusing Temp.

The temperature of the Alloy Thermal-Link which causes it to change its state of conductivity is measured with silicone oil bath in which the temperature is increased at the rate of 0.5 °C to 1 °C / minute, with a detection current up to 10 mA as the only load.

TCR

Temp. Coefficient of Resistance

Relative variation of resistance between two given temp. divided by the difference in the temp. producing it.

— (IEC 60115-1)

Through Hole

Axial, Radial

● Power Supply

● General Lighting

● Power Strip

● Personal Care Application

● Smart Home

● Security & Protection

View Product Structure, Principle, Application Video

Fuse quality 拷贝 4.png

SETsafe | SETfuse Quality Policy

Provide Industry-Leading Products

Raw-materials Supplier

Select critical raw materials: Must be from a manufacturer with quality management system (ISO9001, IATF16949) certification.

Annual or Quarterly Audits.

IQC (Incoming Quality Check)

AQL(MIL-STD-105E), Dimensions, Function, Visual Inspection, RoHS & REACH Test.

Document

Formulate corresponding incoming inspection specifications (01-QA-06-xxx) for each key material according to design data such as material technical indicators.

Testing Equipment and Tools

Projector, Resistance meter, Tool Microscope, Salt Spray Tester, Universal Material Testing Machine, Spectrum Analyzer, etc.


Manufacturing Process

Online Inspection and Testing (Function 100% Automatic Testing).

Document

Process Flow Chart.

Failure Mode and Effects Analysis (FMEA).

Quality Control Flow Chart (QCFC).

Standard Inspection Procedure (SIP).

Work Instruction (WI).

Online Testing and Inspection

Resistance test system (100% Automatic Testing).

100% Visual Inspection.

etc.

TRXF online EN.png

IPQC (In Process Quality Control) Inspection

AQL(MIL-STD-105E), Dimensions Inspection, Function Test, Visual Inspection.

FQC ( Final Quality Control)

AQL(MIL-STD-105E), Dimensions Inspection, Function Test, Visual Inspection, RoHS & REACH Test.

Reliability Test

T Test specification (01-TE-01-3003-001)

Including 26 items of Appearance Requirements, Electrical Performance, Mechanical Performance, Soldering Performance, Environmental Test and Life Test. e.g.

Insulation Resistance Test.

Temperature Cycle Test.

Functioning Temperature Test.

Surge Test.

etc.

OQC (Outgoing Quality Control)

AQL(MIL-STD-105E), Packaging, Labeling, Quantity Inspection.

Agency

Agency (Safety Certificate) Annual, Quarterly Audits.

Management System

ISO9001, (TUV approved and issued certificate).

ISO14001, ISO45001, etc.

Click to view the certificate

Environmental

RoHS & REACH Compliant.

SETsafe | SETfuse

Cold Resistance Test

1. If product TCR is not less than 350 (10^-6/°C), the measured resistance value shall be corrected as the relative resistance value under 25 °C according to TCR formula.

2. Resistance Measurement (4-terminal test)

Replacement

As TRXF is a non-resettable product, for safety sake, please use the same type of TRXF for replacement.

Usage

1. Do not touch the resistor body or pins directly when power is on, to avoid burn or electric shock.

2. When air pressure is from 80 kPa to 106 kPa, the relative altitude shall be +2000 m to - 500 m.

Storage

1. Please store TRXF with ambient temp. 10 °C ~ 30 °C and relative humidity 30% ~ 75%.

2. Do not store the TRXF at the high temperature, high humidity or corrosive gas environment, avoid influencing the solderability of the pins, please use them up within 1 year after receiving the goods.

Soldering Parameters

Wave Soldering Parameters (For Reference Only)

The Wave Soldering Parameters are for reference only, before TRXF is for practice usage, relative validation is recommended.
