SETsafe | SETfuse operates 10+ functional and performance testing laboratories, equipped with over 300 devices, enabling the execution of 1,000+ test items. These include, but are not limited to, the Surge Test Laboratory, Electrical Testing Laboratory, Temperature Testing Laboratory, Material Testing Laboratory, Environmental Qualification Test Laboratory, Environmental Testing Laboratory, Thermal Analysis Laboratory, Durability Testing Laboratory, Mechanical Testing Laboratory, and Product Application Testing Laboratory.
Surge Test Laboratory
Test Items Include but are not Limited to:
Voltage Protection Level, Operating Duty Cycle, Maximum Energy Test, Residual Voltage Test, Varistor Voltage Test, Capacitance Test, Limit Voltage, Surge Current Test, Surge Voltage Test, DC Breakdown Voltage, Impulse Breakdown Voltage, Impulse Current, Impulse Voltage, Forward Surge Voltage, Clamping Voltage , Surge Life, Surge Extreme Limit, etc.
Reference Test Standards:
IEC 61643-11, IEC 61643-31, IEC 61643-311, IEC 60060-1, UL 1449, IEC 61051-1, JESD 210A, YD/T 1235.1, YD/T 1235.2, GB/T10193, GB/T18802.31, GB/T1 8802.11, GB/T18802.311, GB/T9043…
8/20 &10/350μs Impulse Current Test Equipment
10/350μs Impulse Current Test Equipment
8/20μs Impulse Current Test Equipment......
Electrical Testing Laboratory
Test Items Include but are not Limited to:
Fusing Time Characteristics, Internal Resistance, Fusing Current, Instantaneous Overload Current, Electrical Strength, Insulation Resistance, Tolerance Test, Withstand Voltage Test, Thermal Stability Test, Short-Circuit Current Characteristics, Instantaneous Overvoltage, Voltage Drop Test, Accidental Overload, Fuse Test, Rated Current Test, Temperature Rise and Dissipated Power Test, Breaking Capacity Test, Cut-Off Current Characteristics, I²t Characteristic Testing, Fluctuating Current Cycle Load Test...
Reference Test Standards:
IEC 60691, UL1449, IEC 61643-11, UL 248-1, UL 248-2, IEC 60115-1, JIS-C5201, UL1412, SJ 2865, IEC60269, GB/T 9816.1, GB/T 9816.2, GB/T 9816.3, GB/T 1 0193, GB/T18802.11, GB/T 9364-1, GB/T 9364-2, GB/T 5729, GB/T 5729, GB/T 17626.5, GB/T 13539, UL 248...
DC Short Circuit Current Test Equipment
Fault Simulation Testing Equipment
Intermediate Current Testing Equipment
Intermediate Current Test Equipment......
Temperature Testing Laboratory
Test Items Include but are not Limited to:
Temperature Sensitive Speed, Holding Temperature, Functioning Temperature, Functioning Temperature with Load, Extreme Temperature...
Reference Test Standards:
IEC 60691, GB/T 9816.1, GB/T 9816.2...
General baking oven Constant temperature test chamber Functioning temperature test equipment......
Materials Testing Laboratory
Test Items Include but are not Limited to:
Pull-out Force Testing, Bending Test, Pressure Test, Terminal Strength Verification, Vickers Hardness, Coating Thickness Measurement, Fourier Infrared Analysis, Particle Size Analysis, Microscopic Analysis, Needle Flame Testing, Glow Wire Testing, Tracking Resistance Testing, Horizontal/Vertical Burning, X-Ray Analysis...
Reference Test Standards:
ISO 6507-2, ASTM E384, IEC62321, ISO3497, ASTM B568, ISO 11357, UL746A, IEC60695, IEC60112, UL94, IEC60950-1, IEC60950-11, GB/T 228.1, GB/T6397, GB/T16825.1, GB /T4340.2, GB/T16921, GB/T6040, GB/T19466.3, GB/T5169, IEC60695, GB/T4207, GB/T5169.5, GB/T2408, GB/T5169.6, GB/T26592...
Polarization Energy Dispersive X-ray Fluorescence Spectrometer
Fourier Transform Infrared Spectrometer
X-ray fluorescence coating thickness gauge......
Environmental Qualification Test Laboratory
Test Items Include but are not Limited to:
Temperature and Humidity Cycle Test, High and Low Temperature Cycle Test, High Temperature and High Humidity Test, High Temperature Test, Moisture Treatment, Steady State Humidity Test, Temperature Shock Test, Salt Spray Test, Steady State Humidity Test, Climate Sequence Test, Rapid Temperature Change, High Temperature Storage, High Temperature Reverse Bias Aging HTRB, Low Temperature Storage, High Pressure Cooking, High Accelerated Temperature and Humidity Unbiased Test, Hot and Cold Shock, Stress Corrosion Cracking Resistance Test, Ball Pressure Test...
Reference Test Standards:
IEC 60691, IEC 60068-2-14, IEC 60068-2-78, IEC 61051-1, IEC 60068-2-32, IEC60068-2-67, IEC 60068-2-11, JESD22-A103E, MIL-STD- 750, JESD22-A119A, IEC60068-2-1, JESD22-A102E, JESD22-A118A, JESD22-A106B, JESD22-A104C, IEC60269-1, UL 248, IEC60068-2-1, IEC60068-2-2, IEC6006 8-2 -64, GJB 360B, GB/T 10193, GB/T 10125, GB/T 13539-1, GB/T2423.22, GB/T2423.1, GB/T2423.2, GB/T2423.17, GB/T2423.10, GB/T2423.56… …
Climate simulation test chamber
Temperature shock test chamber (2 chambers)
Constant temperature and humidity test chamber......
Environmental Testing Laboratory
Test Items Include but are not Limited to:
Environmental Testing (RoHS, REACH), Elemental Analysis...
Reference Test Standards:
IEC62321-3-1......
Thermal Analysis Laboratory
Test Items Include but are not Limited to:
Surface Temperature Rise Test, Heating Test, Finite Element Simulation...
Reference Test Standards: T/CEEIA 339, GB/T 9816.2......
Durability Testing Laboratory
Test Items Include but are not Limited to:
Standard Aging Test, Long-Term High Temperature Load Test, Temperature Life Test, Resistance to Welding Heat, Weldability...
Reference Test Standards:
IEC 60691, IEC 61051, IEC60068-2-20, GB/T 2423.28, GB/T 10193...
Mechanical Testing Laboratory
Test Items Include but are not Limited to:
Drop Testing, Vibration Testing, Shock Testing...
Reference Test Standards:
IEC 60068-2-31, IEC 60068-2-6, IEC 60068-2-32, ISTA-1A/ISTA-2A/ISTA-6A, GJB 150A, GB/T 2423.8, GB/T 2423.43...
Product Application Testing Laboratory
Test Items Include but are not Limited to:
Customer-specific Combination Testing, Customer's end-product Simulation Testing...
Reference Test Standards:
According to customer terminal product standard requirements.
For further information about the SETsafe | SETfuse Testing Center (Laboratory) Learn more
END.
Update: Mar 2025
